JACKS AND PLUGS
FAX: 773 792-2129 1/4" AND .206" COMMERCIAL PHONE PLUGS
* Please visit the product pages on our website for the most up-to-date product information
151
1/4" COMMERCIAL PHONE
PLUGS (continued)
3-CONDUCTOR/PLASTIC OR
SHIELDED HANDLES
.206" COMMERCIAL
PHONE PLUGS
PHONE PLUGS FOR
POLARIZED CONNECTIONS
.206" Diameter
Number 60
Number 190A
Number 190
Numbers S250, S255
FEATURES
For applications requiring polarization (use of plugs of different
sizes) to prevent insertion of incorrect equipment Littel-Plug ?
phone plugs featuring a sleeve and tip diameter of .206" are
available. Mate with Number S128 Extension Jax ? and S11
Littel Jax ? jacks. Number S260 used interchangeable with
Military Type M642/51 (Switchcraft Number 480) plugs. Mate
with jacks S12B, S13B, M444, MT342B, MT344B and others.
Part
Typical
Handle Part
Number
? 60
? 90
Terminals
Mating Jack 2
Handle
Black
Shielded
Number
M1001
T10451
2-CONDUCTOR PLUGS PART NUMBERS
190
Solder Lug
12B
Shielded
Handle: T10141
Insulator: A10063
Part
Number
Terminals
Typical Mating
Jack 1
Handle
Handle Part
Number
Shielded 2-piece 1
190A,190B
& 190BL
1. 2-piece shielded handle with built-in cable clamp for .25" diameter cable.
S250
S280
Solder Lug &
Cable Clamp
S11
Black
Shielded
M1002
T10581
A10071
Handles: Number T11231 , handle; Number T11241 , cap; Number
A10064 , insulating tube; Number T1125 , rubber washer.
2. Other Mating Plugs are available.
3-CONDUCTOR PLUGS PART NUMBERS
? Special order only. Contact Switchcraft.
Screw
(Replacement
S260
Screw Part No.
S267
P10292)
2 required
Solder Lug &
Cable Clamp
S12B
Black
M1002
1. Switchcraft ? mating jacks.
Number 60
Number 90
Number S260
DIMENSIONS ARE FOR REFERENCE ONLY
Inch
(mm)
SWITCHCRAFT, INC. 5555 N. Elston Ave. ? Chicago, IL 60630
